Marmo Elettromeccanica YS20 3x3 Chamfer Step - 20mm Diamond Profiling Wheel - Line 60 CNC Bore 35mm

(0 review)
$ 645.75 $ 645.75
$ 195.00
  • Brand
  • Position
  • Kit Type
Contact Us
Terms and Conditions
Position 1, 2, 3, 3X, 4, 5, 6, Full Set
Kit Type EHS Kit, Electroplated Kit, Standard Kit
Brand Marmo Elettromeccanica

Marmo Elettromeccanica YS20 3x3 Chamfer Step - 20mm Diamond Profiling Wheel - Line 60 CNC Bore 35mm

Marmo Elettromeccanica YS20 3x3 Chamfer Step - 20mm Diamond Profiling Wheel - Line 60 CNC Bore 35mm. This listing covers 24 orderable configurations built from 14 manufacturer part codes — Kit Type: EHS Kit, Electroplated Kit, Standard Kit; Position: 1, 2, 3, 3X, 4, 5, 6, Full Set. Select the configuration you need from the options above; the manufacturer code for each configuration is shown in the specifications table below.

Features

  • 14 distinct manufacturer part codes covered by this listing.
  • Kit Type options: EHS Kit, Electroplated Kit, Standard Kit.
  • Position options: 1, 2, 3, 3X, 4, 5, 6, Full Set.
  • Suitable for: Granite, Ceramic/Quartz, Marble (varies by kit type).
  • CNC operating parameters published per manufacturer code (see Specifications).
PropertyDetail
SC61120
1 / Standard Kit		Max spindle speed 6,000 rpm · Min spindle speed 4,000 rpm · Feed rate 31.5–98.43 in/min (800–2,500 mm/min) · Stock removal 0.012–0.02 in (0.3–0.5 mm)
SC62120
2 / Standard Kit		Max spindle speed 6,000 rpm · Min spindle speed 4,000 rpm · Feed rate 31.5–98.43 in/min (800–2,500 mm/min) · Stock removal 0.012–0.016 in (0.3–0.4 mm)
SC63120
3 / Electroplated Kit; 3 / Standard Kit		Max spindle speed 5,000 rpm · Min spindle speed 3,000 rpm · Feed rate 31.5–78.74 in/min (800–2,000 mm/min) · Stock removal 0.006–0.008 in (0.15–0.2 mm)
SC64120
4 / EHS Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC64140
4 / Electroplated Kit; 4 / Standard Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC65120
5 / EHS Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC65140
5 / Electroplated Kit; 5 / Standard Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC66120
6 / EHS Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC66140
6 / Electroplated Kit; 6 / Standard Kit		Max spindle speed 3,000 rpm · Min spindle speed 2,000 rpm
SC67120
1 / Electroplated Kit		Max spindle speed 6,000 rpm · Feed rate 31.5–98.43 in/min (800–2,500 mm/min) · Stock removal 0.012–0.02 in (0.3–0.5 mm)
SC68120
2 / Electroplated Kit		Max spindle speed 6,000 rpm · Feed rate 31.5–98.43 in/min (800–2,500 mm/min) · Stock removal 0.012–0.016 in (0.3–0.4 mm)
SCE61120
1 / EHS Kit		Max spindle speed 6,000 rpm · Min spindle speed 3,000 rpm · Feed rate 59.06–393.7 in/min (1,500–10,000 mm/min) · Stock removal 0.012–0.02 in (0.3–0.5 mm)
SCE62120
2 / EHS Kit		Max spindle speed 6,000 rpm · Min spindle speed 3,000 rpm · Feed rate 59.06–393.7 in/min (1,500–10,000 mm/min) · Stock removal 0.012–0.016 in (0.3–0.4 mm)
SCE63120
3 / EHS Kit		Max spindle speed 6,000 rpm · Min spindle speed 3,000 rpm · Feed rate 59.06–393.7 in/min (1,500–10,000 mm/min) · Stock removal 0.006–0.008 in (0.15–0.2 mm)

Wear appropriate PPE (ANSI Z87.1 safety glasses, hearing protection, gloves, and dust or respiratory protection). Never exceed the wheel’s rated spindle speed — observe the min/max rpm listed in the specifications. Inspect the wheel before each use and follow the machine manufacturer’s safety instructions.
